class: left, bottom, inverse, title-slide # Bayesian Statistics ## Lecture 7: Markov chain Monte Carlo (MCMC) Methods ### Yanfei Kang ### 2019/10/18 (updated: 2019-11-04) --- # Limitations of independent Monte Carlo methods - The ability to sample from the posterior distribution is essential to the practice of Bayesian statistics. - Direct sampling - Sometimes difficult to find the inverse function. - Rejection sampling and importance sampling - Doesn’t work well if proposal is very different from the target. - Yet constructing a proposal similar to the target can be difficult. - Intuition of MCMC - Instead of a fixed proposal, use an adaptive proposal. --- class: inverse, center, middle # Markov chain --- # What is Markov chain? A *Markov chain* is a sequence of random variables `\(\theta^1, \theta^2, \cdots,\)` for which, for any `\(t\)`, the distribution of `\(\theta^t\)` given all previous `\(\theta\)`'s depends only the most recent value, `\(\theta^{t-1}\)`. --- # The key to MCMC's success - Not the Markov property. - But the approximate distributions are improved at each step in simulation (in the sense of converging to the target distribution). --- class: inverse, center, middle # The Metropolis algorithm --- # The Metropolis algorithm - The Metropolis algorithm was developed in a 1953 paper by Metropolis, Rosenbluth, Rosenbluth, Teller and Teller. - The aim is to simulate `\(x \sim p(x)\)` where `\(p(x)\)` is called the target density. - We will need a proposal density `\(q\left(x^{[\text {new}]} | x^{[\text {old }]} \right).\)` - For example one choice of `\(q\)` is `$$x^{[\mathrm{new}]} \sim N\left(x^{[\mathrm{old}]}, 1\right).$$` - This is called a Random Walk proposal. --- # Symmetric proposal - An important property of `\(q\)` in the Metropolis algorithm is symmetry of the proposal `$$q\left(x^{[\text {new}]} | x^{[\text {old}]}\right)=q\left(x^{[\text {old}]} | x^{[\text {new}]} \right).$$` - Can you confirm this is true? --- # Accept and reject To make sure this Markov chain converges to our target, we need to include the following. 1. At step `\(i+1\)`, set `\(x^{[\mathrm{old}]} = x^{[i]}\)`. 2. Generate `\(x^{[\mathrm{new}]} \sim N\left(x^{[\mathrm{old}]}, 1\right)\)`, and compute `$$\alpha=\min \left(1, \frac{p\left(x^{[\mathrm{new}]}\right)}{p\left(x^{[\mathrm{old}]}\right)}\right).$$` 3. Set `\(x^{[i+1]} = x^{[\mathrm{new}]}\)` with probability `\(\alpha\)` (accept); set `\(x^{[i+1]} = x^{[\mathrm{old}]}\)` with probability `\(1-\alpha\)` (reject). --- # Example .pull-left[ Here is a target distribution to sample from. It’s the weighted sum of two normal distributions. Sample using the Metropolis algorithm, and plot the trace. ```r p <- 0.4 mu <- c(-1, 2) sd <- c(0.5, 2) f <- function(x) { p * dnorm(x, mu[1], sd[1]) + (1 - p) * dnorm(x, mu[2], sd[2]) } curve(f(x), -4, 8, n = 301, las = 1) ``` ] .pull-right[ ![](BS-L7-MCMC_files/figure-html/unnamed-chunk-1-1.png)<!-- --> ] --- # ### Define `\(q\)` ```r q <- function(x) rnorm(1, x, 4) ``` ### Define the step ```r step <- function(x, f, q) { ## Pick new point xp <- q(x) ## Acceptance probability: alpha <- min(1, f(xp) / f(x)) ## Accept new point with probability alpha: if (runif(1) < alpha) x <- xp ## Returning the point: x } ``` --- # Let's run it ```r run <- function(x, f, q, nsteps) { res <- matrix(NA, nsteps, length(x)) for (i in seq_len(nsteps)) res[i,] <- x <- step(x, f, q) return(res) } res <- run(-10, f, q, 1100) ``` --- # Trace plot (1100 samples, with the first 100 burn-in) <img src="BS-L7-MCMC_files/figure-html/unnamed-chunk-5-1.png" style="display: block; margin: auto;" /> --- # Does it resembles our target? .pull-left[ ```r hist(res[101:1100], 50, freq=FALSE, main="", ylim=c(0, .4), las=1, xlab="x", ylab="Probability density") z <- integrate(f, -Inf, Inf)$value curve(f(x) / z, add=TRUE, col="red", n=200) ``` ] .pull-right[ ![](BS-L7-MCMC_files/figure-html/unnamed-chunk-6-1.png)<!-- --> ] --- # Lab 1. Try 10000 samples. 2. Try different initial values (even very unrealistic ones). 3. Try different values of standard deviation for `\(q\)` (e.g., 50, 0.1). Plot their trace plots together with the previous one. Calculate their acceptance rates. Your findings? 4. Based on 3, plot the autocorrelation plots of the three traces. Your findings? --- # Findings - For a random walk proposal it is not good to have an acceptance rate that is too high or too low. - What exactly is too high and too low? - It depends on many things including the target and proposal. - A rough rule is to aim for an acceptance rate between 20% and 70%. - If your acceptance rate is outside this range the proposal variance can be doubled or halved. --- # Findings - It is better to have lower correlation in the Markov chain. - The efficiency of the chain can be measured using the effective sample size. - The effective sample size can be computed using the function `effectiveSize` in the R Package **coda**. - Obtain an effective sample size for your samples. --- class: inverse, center, middle # The Metropolis Hastings algorithm --- # The Metropolis Hastings algorithm 1. At step `\(i+1\)`, set `\(x^{[\mathrm{old}]} = x^{[i]}\)`. 2. Simulate `\(x^{[\mathrm{new}]}\)` from the proposal density `\(q\left(x^{[\mathrm{new}]}|x^{[\mathrm{old}]}\right)\)`, and compute `$$\alpha=\min \left(1, \frac{p\left(x^{[\mathrm{new}]}\right) q\left(x^{[\mathrm{old}]}|x^{[\mathrm{new}]}\right)}{p\left(x^{[\mathrm{old}]}\right) q\left(x^{[\mathrm{new}]}|x^{[\mathrm{old}]}\right)}\right).$$` 3. Set `\(x^{[i+1]} = x^{[\mathrm{new}]}\)` with probability `\(\alpha\)` (accept); set `\(x^{[i+1]} = x^{[\mathrm{old}]}\)` with probability `\(1-\alpha\)` (reject). --- # Why does this work? - To satisfy the existence stationary distribution, we need `$$p(x^{[\mathrm{new}]}) P\left(x^{[\mathrm{old}]}|x^{[\mathrm{new}]}\right) = p(x^{[\mathrm{old}]}) P\left(x^{[\mathrm{new}]}|x^{[\mathrm{old}]}\right).$$` - `\(P\)` is the transition probability. And we have `$$P\left(x^{[\mathrm{old}]}|x^{[\mathrm{new}]}\right) = q\left(x^{[\mathrm{old}]}|x^{[\mathrm{new}]}\right)\alpha(x^{[\mathrm{old}]}|x^{[\mathrm{new}]}).$$` `$$P\left(x^{[\mathrm{new}]}|x^{[\mathrm{old}]}\right) = q\left(x^{[\mathrm{new}]}|x^{[\mathrm{old}]}\right)\alpha(x^{[\mathrm{new}]}| x^{[\mathrm{old}]}).$$` - We need to have an acceptance ratio that fulfills the equations above. One common choice is the Metropolis-Hastings choice. --- # Choices for the Metropolis Hastings algorithm - Random walk Metropolis Hastings `\(x^{[\mathrm{new}]} = x^{[\mathrm{old}]} + \epsilon\)`, where `\(\epsilon \sim g\)` and `\(g\)` is a probability density symmetric about 0. **Show that in this case `\(q\left(x^{[\mathrm{new}]}|x^{[\mathrm{old}]}\right) = q\left(x^{[\mathrm{old}]}|x^{[\mathrm{new}]}\right)\)`**. - Independent Metropolis Hastings `\(q\left(x^{[\mathrm{new}]}|x^{[\mathrm{old}]}\right) = q\left(x^{[\mathrm{new}]}\right)\)`, and `\(q\left(x^{[\mathrm{old}]}|x^{[\mathrm{new}]}\right) = q\left(x^{[\mathrm{old}]}\right)\)`. --- # 2d example This is a function that makes a multivariate normal density given a vector of means and variance-covariance matrix. ```r make.mvn <- function(mean, vcv) { logdet <- as.numeric(determinant(vcv, TRUE)$modulus) tmp <- length(mean) * log(2 * pi) + logdet vcv.i <- solve(vcv) function(x) { dx <- x - mean exp(-(tmp + rowSums((dx %*% vcv.i) * dx))/2) } } ``` --- # Target density .pull-left[ ```r mu1 <- c(-1, 1) mu2 <- c(2, -2) vcv1 <- matrix(c(1, .25, .25, 1.5), 2, 2) vcv2 <- matrix(c(2, -.5, -.5, 2), 2, 2) f1 <- make.mvn(mu1, vcv1) f2 <- make.mvn(mu2, vcv2) f <- function(x) f1(x) + f2(x) x <- seq(-5, 6, length=71) y <- seq(-7, 6, length=61) xy <- expand.grid(x=x, y=y) z <- matrix(apply(as.matrix(xy), 1, f), length(x), length(y)) image(x, y, z, las=1) contour(x, y, z, add=TRUE) ``` ] .pull-right[ ![](BS-L7-MCMC_files/figure-html/unnamed-chunk-8-1.png)<!-- --> ] --- # Metropolis sampling .pull-left[ ```r q <- function(x, d=8) x + runif(length(x), -d/2, d/2) x0 <- c(-4, -4) set.seed(1) samples <- run(x0, f, q, 1000) image(x, y, z, xlim=range(x, samples[,1]), ylim=range(x, samples[,2])) contour(x, y, z, add=TRUE) lines(samples[,1], samples[,2], col="#00000088") ``` ] .pull-right[ ![](BS-L7-MCMC_files/figure-html/unnamed-chunk-9-1.png)<!-- --> ] --- # More samples .pull-left[ ```r samples <- run(x0, f, q, 100000) smoothScatter(samples) contour(x, y, z, add=TRUE) ``` ] .pull-right[ ![](BS-L7-MCMC_files/figure-html/unnamed-chunk-10-1.png)<!-- --> ] --- # Indirect method v.s. Metropolis Hastings - Some similarities - Both require a proposal. - Both are more efficient when the proposal is a good approximation to the target. - Both involve some form of accepting/rejecting. - Some differences - Indirect method produces an independent sample, MH samples are correlated. - Indirect method requires `\(p(x)/q(x)\)` to be finite for all `\(x\)`. - MH works better when `\(x\)` is a high-dimensional vector. --- class: inverse, center, middle # Gibbs sampler --- # Gibbs sampler - The standard Metropolis algorithm updates the entire parameter vector at once with a single step. Hence, a `\(p\)`-dimensional parameter vector must have a `\(p\)`-dimensional proposal distribution `\(q\)`. - The beauty of Gibbs sampling is that it simplifies a complex high-dimensional problem by breaking it down into simple, low-dimensional problems. --- # Gibbs sampler - If it is easy to simulate from the conditional distribution `\(f(x|z)\)` then that can be used as a proposal. - What is the acceptance ratio? `$$\begin{aligned} \alpha &= \mathrm{min} \left(1, \frac{p\left(x^{\text {new}}, z\right) p\left(x^{\text {old}} | z\right)}{p\left(x^{ \text {old}}, z\right) p\left(x^{\text {new}} | z\right)}\right) \\ &= \mathrm{min} \left(1, \frac{p\left(x^{\text {new}} | z\right) p(z) p\left(x^{\text {old }} | z\right)}{p\left(x^{ \text {old}}| z) p(z) p\left(x^{\text {new}} | z\right)\right.}\right) \\ &=1 \end{aligned}.$$` --- # Gibbs sampler - This gives the Gibbs Sampler. If our current state is `\((x^{[i]}, z^{[i]})\)`, then we update our parameter values with the following steps. 1. Generate `\(x^{[i+1]} \sim p\left(x|z^{[i]}\right).\)` 2. Generate `\(z^{[i+1]} \sim p\left(z|x^{[i+1]}\right).\)` - `\(x\)` and `\(z\)` can be swapped around. - It works for more than two variables (think about the case with three parameters). - Always make sure the conditioning variables are at the most recent state. --- # Lab Simulate using Gibbs sampler from a bivariate Normal distribution with mean `\((\mu_1, \mu_2)\)` and known variance matrix `\(\Sigma=\left(\begin{array}{cc}{\sigma_{1}^{2}} & {\rho} \\ {\rho} & {\sigma_{2}^{2}}\end{array}\right)\)`, and plot the sample traces. --- # Gibbs sampler - Advantages of Gibbs sampling - No need to tune proposal distribution. - Proposals are always accepted. - Disadvantages of Gibbs sampling - Need to be able to derive conditional probability distributions. - Need to be able to (cheaply) draw random samples from conditional probability distributions. - Can be very slow if parameters are correlated because you cannot take "diagonal" steps. --- # Metropolis within Gibbs - Even if the individual conditional distributions are not easy to simulate from, Metropolis Hastings can be used within each Gibbs step. - This works very well because it breaks down a multivariate problem into smaller univariate problems. - We will practice some of these algorithms in the context of Bayesian Inference. --- # Summary - Markov chain. - Metropolis. - Metropolis Hastings. - Gibbs sampler. - Metropolis Hastings within Gibbs.
